Specifications

• ENGINE

  add remove
  • Engine Type:
    450cc liquid-cooled DOHC 4-stroke; 4 titanium valves
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.82
  • Stroke (in):
    2.39
  • Displacement (cc):
    450
  • Carburetion Brand:
    Mikuni
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Bore x Stroke:
    97.0mm × 60.8mm
  • Compression ratio:
    13.0:1
  • Fuel Delivery:
    Mikuni® fuel injection, 44mm
  • Transmission:
    5-speed; multiplate wet clutch
  • Final Drive:
    Chain
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Overdrive:
    Yes
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    85.8
  • Width (in):
    32.7
  • Height (in):
    50.2
  • Wheelbase (in):
    58.3
  • Ground Clearance (in):
    13.8
  • Fuel Capacity (gal):
    1.6
  • Engine Displacement to Weight (cc):
    1.88
  • Wet Weight (lbs):
    240
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Travel (in):
    12.2
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    12.4
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    KYB
  • Rear Suspension Brand Name:
    KYB
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubed
  • Tires:
    Standard
  • Tire Brand:
    Dunlop®
  • Front Tire (Full Spec):
    Dunlop® MX33F 80/100 R21
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    10.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    9.4
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    38
  • Number Of Seats:
    1
  • Detachable Passenger Seat:
    Not Available
  • Seat Backrest:
    Not Available
  • Grab Rail or Strap:
    Not Available
