Specifications

• ENGINE

  add remove
  • Cylinders:
    3
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    115
  • Torque (Ft Lbs):
    96
  • Torque RPM:
    5000
  • Bore (mm):
    84
  • Stroke (mm):
    80
  • Displacement (cc):
    1330
  • Compression Ratio:
    12.2:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual / Automatic Clutch
  • Number Of Speeds:
    6
  • Primary Drive (Rear Wheel):
    Belt
  • Reverse:
    Yes
  • Gear Ratio (1):
    2.47
  • Gear Ratio (2):
    1.88
  • Gear Ratio (3):
    1.52
  • Gear Ratio (4):
    1.27
  • Gear Ratio (5):
    1.07
  • Gear Ratio (6):
    0.91
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    109.3
  • Width (in):
    61.2
  • Height (in):
    57.6
  • Wheelbase (in):
    67.5
  • Ground Clearance (in):
    4.5
  • Dry Weight (lbs):
    990
  • Payload Capacity (lbs):
    494
  • GVWR (lbs):
    1481
  • Fuel Capacity (gal):
    7
  • Storage Capacity (cuft):
    4.8
  • Storage Capacity (l):
    117
  • Engine Displacement to Weight (cc):
    1.34
  • Towing Capacity (lbs):
    400
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double A-Arm
  • Front Travel (in):
    6.9
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    6
  • Number Rear Shock Absorbers:
    1
  • Front Suspension Brand Name:
    Sachs
  • Rear Suspension Brand Name:
    Sachs
• WHEELS & TIRES

  add remove
  • Front Tire Width:
    165
  • Front Tire Aspect Ratio:
    55
  • Front Wheel Diameter:
    15
  • Rear Tire Width:
    225
  • Rear Tire Aspect Ratio:
    50
  • Rear Wheel Diameter:
    15
  • Front Tire (Full Spec):
    XPS Roadster K165/55 R15 69H
  • Rear Tire (Full Spec):
    XPS Roadster K225/50 R15 84H
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    10.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    10.6
