Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valves:
    2
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    SOHC
  • Bore (in):
    2.84
  • Stroke (in):
    2.41
  • Displacement (cc):
    249
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Bore x Stroke:
    72.0 mm (2.835 in) x 61.2 mm (2.409 in)
  • Compression Ratio:
    9.2:1
  • Fuel System:
    Suzuki fuel injection
  • Lubrication:
    Wet sump
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    5
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    81.5
  • Width (in):
    29.5
  • Height (in):
    42.3
  • Wheelbase (in):
    54.1
  • Fuel Capacity (gal):
    3.2
  • Wet Weight (lbs):
    326
• SUSPENSION

  add remove
  • Front Suspension Type:
    Telescopic Fork
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Rear Suspension Material:
    Steel
  • Steering Damper:
    No
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Chromed:
    Yes
  • Tube / Tubeless:
    Tubed
  • Front Tire (Full Spec):
    90/90 R18M/C 51S
  • Rear Tire (Full Spec):
    110/90 R18M/C 61S
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Drum
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
