Specifications

• ENGINE

  add remove
  • Engine Type:
    Horizontal In-line
  • Cylinders:
    4
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Valves:
    16
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    DOHC
  • Bore (in):
    3.11
  • Stroke (in):
    2
  • Displacement (cc):
    998
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • US Miles Per Gallon (Hwy):
    36
  • Bore x Stroke:
    79.0mm x 50.9mm
  • Compression ratio:
    12.0:1
  • Fuel Delivery:
    Fuel injection with YCC-T
  • Transmission:
    6-speed; wet multiplate assist and slipper clutch
  • Final Drive:
    Chain
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual
  • Number Of Speeds:
    6
  • Overdrive:
    No
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (in):
    82.7
  • Width (in):
    31.5
  • Height (in):
    45.9
  • Wheelbase (in):
    55.3
  • Ground Clearance (in):
    5.3
  • Fuel Capacity (gal):
    4.5
  • Engine Displacement to Weight (cc):
    2.14
  • Wet Weight (lbs):
    467
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1.7
  • Front Travel (in):
    4.7
  • Front Adjustable Fork Pre-Load:
    Yes
  • Front Adjustable Rebound Damping:
    Yes
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Travel (in):
    4.7
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Rear Adjustable Rebound Damping:
    Yes
  • Number Rear Shock Absorbers:
    1
  • Rear Suspension Material:
    Aluminum
  • Air Adjustable:
    No
  • Front Suspension Brand Name:
    KYB
  • Rear Suspension Brand Name:
    KYB
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Tube / Tubeless:
    Tubeless
  • Tires:
    Standard
  • Tire Brand:
    Bridgestone®
  • Front Tire (Full Spec):
    Bridgestone® Battlax Hypersport™ S22 120/70 ZR17
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Front Brake Diameter (in):
    12.6
  • Rear Brake Type:
    Hydraulic Disc
  • Rear Brake Diameter (in):
    8.7
  • Regenerative Braking:
    Not Available
  • Regenerative Deceleration:
    Not Available
• SEATS

  add remove
  • Seat Type:
    One-Piece
  • Seat Location:
    Driver and Passenger
  • Seat Material:
    Vinyl
  • Seat Specifications:
    Standard
  • Seat Height (in):
    32.9
  • Number Of Seats:
    2
  • Detachable Passenger Seat:
    Not Available
  • Grab Rail or Strap:
    Standard
